Pantalla Grafica LCD BGG12832-02
Modelo No. BGG12832-02
Outline size（mm）： 84.00 × 44.00 × 14.10
Viewing Area：70.00 × 20.00
Active Area： 66.52 × 16.60
Controller IC： AIP31020 or Eqv.
Interface： SPI & Parallel
Remarks： 1×18PIN
Backlight：LED
Part Number: BGB12832-02
● Character LCD 128 x 32 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller (AIP31020 or Equivalent)
● +3.3V / +5.0V power supply
● 1/32 duty, 1/5bias
● Viewing Direction: 6H / 12H
● Interface: 6800 4/8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
<!--[if !supportLineBreakNewLine]-->
Pantalla de Blaze es uno de los mejores fabricantes de China gráfico LCD pantalla BGG12832-02 y proveedores. Siempre estamos a su servicio.
