TFT 4,3 pouces
Display Format Picture Model No. Size
(inch)
Outline Dimension
(mm)
Viewing Area
(mm)
Active Area
(mm)
View Direction Interface IC Part No. Control-Board Brightness
(cd/m²)
Recommended Touch Screen Temperature
(°C)
O-Film
480x272
BDT-T4340-05
BDT-T4340-05 4.3“ 105.50 x 67.20 x 5.80 95.04 × 53.86 12H 16BIT RGB FAS506
480x272
BDT-T4340-04A
BDT-T4340-04A 4.3" 105.50 x 67.20 x 4.38 95.04 × 53.86 12H 24BIT RGB ST7257-G4-1C.
480x272
BDT-T4340-04
BDT-T4340-04 4.3” 105.40 x 67.10 x 4.60 95.04 × 53.86 12H 24BIT RGB ILI6480H. 350
480x272
BDT-T4340-02
BDT-T4340-02 4.3“ 105.40 x 67.10 x 2.90 95.40 × 53.86 12H 24BIT RGB ILI6480H.
480x272
BDT-T4340-01
BDT-T4340-01 4.3" 105.40 x 67.10 x 2.90 95.40 × 53.86 12H 24BIT RGB ILI6480H.
