Графический ЖК Индикатор BGG12832-04
Model No. BGG12832-04
Outline size（mm）： 62.50 × 27.00 × 2.00
Viewing Area： 56.60 × 15.20
Active Area： 56.03 × 14.53
Controller IC： ST7565R or Eqv.
Interface： parallel
Backlight：NONE
Remarks： 1×30 PIN
Part No. ：BGG12832-04
● Resolution 128×32 Dots
● DFSTN/NEGATIVE/TRANSMISSIVE
● Built-in controller (ST7565R)
● +3.0V power supply
● 1/33 Duty , 1/5 Bias
● Viewing Direction: 12H
● Interface: 6800/8080 8-bit parallel interface
● Backlight (Side LED): NONE
● Temp: N.T / W.T / Super W.T
Blaze Display is one of the best China Graphic LCD Display BGG12832-04 manufacturers and suppliers. We are always at your service.
