Pantalla Gráfica LCD BGB12232-C03
Modelo No. BGB12232-C03
Outline size（mm）： 65.60 × 29.20 × 5.40
Viewing Area：54.80 × 19.10
Active Area： 48.76 × 15. 32
Controller IC： SBN1661G.
Interface： SPI & Parallel
Remarks： 1×20PIN
Backlight：LED
Part Number: BGB12232-C03
● Grahpic LCD 122 x 32 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller (SBN1661G or Equivalent)
● +3.3V / +5.0V power supply
● 1/32 duty, 1/5bias
● Viewing Direction: 6H / 12H
● Interface: 6800 8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
