Pantalla Grafica LCD BGB160128-02

Modelo No. BGB160128-02

Outline sizemm): 129.00 × 104.50 × 11.00

Viewing Area101.00 × 82.00

Active Area 95.96 × 76.76

Controller IC RA6963 or Eqv.

Interface 8080 Parallel

Remarks 2×11PIN

BacklightLED

<!--[if !supportLineBreakNewLine]-->
<!--[endif]-->

Part Number: BGB160128-02

● Graphic LCD 160 x 128 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller ((RA6963 or Equivalent)
● +3.3V / +5.0V power supply
● 1/64 duty, 1/9bias
● Viewing Direction: 6H / 12H
● Interface: 8080 8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
