Pantalla Grafica LCD BGB160128-02A
Modelo No. BGB160128-02A
Outline size（mm）： 129.00 × 104.50 × 11.00
Viewing Area：101.00 × 82.00
Active Area： 92.76 × 74.20
Controller IC： SAP1024B or Eqv.
Interface： 8080 Parallel
Remarks： 2×11PIN
Backlight：LED
<!--[if !supportLineBreakNewLine]-->
<!--[endif]-->
Part Number: BGB160128-02A
● Graphic LCD 160 x 128 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller ((SAP1024B or Equivalent)
● +3.3V / +5.0V power supply
● 1/128 duty, 1/12bias
● Viewing Direction: 6H / 12H
● Interface: 8080 8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
