Pantalla Gráfica LCD BGB16032-06

Modelo No. BGB16032-06

Outline sizemm): 122.00 × 44.00 × 13.30

Viewing Area99.00 × 24.00

Active Area 89.55 × 18.19

Controller IC AIP31108 or Eqv.

Interface SPI & Parallel

Remarks 1×20PIN

BacklightLED

Part Number: BGB16032-06

● Graphic LCD 160 x 32 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller (AIP31108 or Equivalent)
● +3.3V / +5.0V power supply
● 1/32 duty, 1/16bias
● Viewing Direction: 6H / 12H
● Interface: 6800 8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
