Pantalla Gráfica LCD BGB16064-02
Modelo No. BGB16064-02
Outline size（mm）： 116.00 × 46.00 × 12.00
Viewing Area：86.00 × 35.20
Active Area： 79.97 × 31.97
Controller IC： ST7920or Eqv.
Interface： SPI & Parallel
Remarks： 2×9PIN
Backlight：LED
<!--[if !supportLineBreakNewLine]-->
<!--[endif]-->
Part Number: BGB16064-02
● Graphic LCD 160 x 64 (dots)
● FSTN-Gray / STN-Gray / STN-YG / STN-Blue
● Built-in controller (ST7920 or Equivalent)
● +3.3V / +5.0V power supply
● 1/32 duty, 1/5bias
● Viewing Direction: 6H / 12H
● Interface: 6800 8-bit parallel
● Backlight (Side LED): White / Green / Blue / Yellow-Green / RGB / Orange / Amber
● Temp: N.T / W.T / Super W.T
